Hazardous Liquid DetectorFDT-TQD18

Short Description:

Various types of detection: flammable and explosive dangerous goods such as gasoline, alcohol, etc., liquid explosives, corrosive solutions such as hydrogen peroxide, various strong acids and alkalis, etc., some toxic and harmful liquids in public places such as many organic solvents , etc. liquid. (See the test report for more details)


Product Details

Product Video

Characteristics

Various types of detection: flammable and explosive dangerous goods such as gasoline, alcohol, etc., liquid explosives, corrosive solutions such as hydrogen peroxide, various strong acids and alkalis, etc., some toxic and harmful liquids in public places such as many organic solvents , etc. liquid. (See the test report for more details)

Easy Operation - Fully automatic operation, no manual reset or manual interpretation required. It can automatically restart after the alarm and continue with the next detection. The detection time is short and the efficiency is high. They can detect metallic and non-metallic packaging at the same time, without affecting each other. With the automatic counting function, each liquid element under inspection and liquid alarm element are counted separately, and metal detection and non-metal detection are counted separately. Rich data interface, which can easily realize data transmission and software update. The instrument has a friendly interface and you can master the test run after a few minutes of training.

No radiation / No consumables / Easy to maintain.

2024070805111371
2024070805125048
2024070805130699

Technical Parameter

Detection Target: flammable liquid in sealed container
Container Material: plastic / glass / metal / ceramic / paper (without aluminum foil liner)
Detectable Liquid Container: 60mm ≤ height ≤ 400mm, 30mm ≤ diameter ≤ 200mm
Dimensions: 520mm (length) x 370mm (width) x 200mm (height)
Power: 50W / Weight: about 8kg
Start-up Time: less than 3 seconds.
Self-test Time: less than 2 seconds.
Selectable Detection Modes: vials, ordinary and special bottles
Ambient Temperature: -10-55 ° C
Relative Humidity: 0-99% RH (non-condensing)
Power Supply: AC100-240V (50 / 60Hz)
Alarm: sound alarm / light alarm / LCD display
