Explosion-Proof Tank FDT-EPT01
According to the "GA 871-2010" explosion-proof tank standard development and production, the use of high strength, impact resistant carbon steel plate, manufactured by special welding technology, from the inner tank, outer tank and energy absorption buffer layer combination. Its explosive disposal performance is superior, the explosive disposal tank has a stable placement of explosive net bag, the bottom of the outer tank with universal wheel, easy to transfer, transportation, can effectively block the No. 8 electric mine explosion caused by the destruction effect, and can prevent the explosive tank after the explosion of the shock wave and debris horizontal diffusion, so as to avoid the damage to the surrounding personnel. As well as the damage to valuable instruments, cultural relics archives and special public places, is the public security, armed police, courts, procuratorates, civil aviation, railway, port, customs, important places and large-scale activities such as explosion-proof safety inspection department necessary equipment.
Technical parameter
● Specifications of explosion-proof tank:
● The inner diameter of the tank is 450mm and the depth is 570mm
● The outer diameter of the outer tank is 580mm and the height is 650mm
● Explosion-proof tank material: the inner and outer tanks are made of 8mm thick high-strength, impact-resistant carbon steel plate, and there is an energy-absorbing buffer layer between the inner and outer tanks.
● Antiknock performance: It can effectively prevent the damage effect caused by the explosion of No. 8 electric mine (equivalent to the explosive power of 1.5Kg TNT), and can accommodate all transverse explosion debris, the outer tank body is complete, no cracks, perforations, no dumping of the tank, no burning, smoke, dust in the tank, and no accessories falling off.
● Weight: 220K
Instruction
● After the discovery of suspicious objects should be put into the explosion-proof tank by professional personnel, and moved to a safe zone;
● When the explosion-proof tank needs to be removed from the explosion-proof tank after being moved to the safety zone, professional tools can be used to remove the suspicious object from the explosion-proof tank after personnel are evacuated;
● When explosives need to be destroyed, the detonator and wire of the explosives should be inserted into the hole of the destruction device and connected with the explosives, and professional explosive disposal personnel should detonate the explosives after the personnel are evacuated to a safe area;
● Do not cover the top of the explosion-proof tank when detonating.
Attention
● The tank should be placed in the space above 6m, and avoid the bearing beam, chandelier and damaged can produce splashing objects hurt;
● Although the tank has certain muffling and explosion-proof functions, the explosion sound is very loud at close distance and indoors. Personnel should keep a safe distance (above 4m) and protect the eardrum;
● The unused explosion-proof tank should be oiled regularly on the active part of the tank to prevent rust, and the debris in the tank and pressure relief cover should be removed in time to ensure clean;
● The explosion-proof tank shall not be used again after blasting.
-
